| Model | DSN - T2513 |
| Product characteristics | Long life |
| Product use | Push and pull |
| Temperature range | -5℃-110℃ |
| Relative humidity | 20%-85% |
| Rated voltage | DC24V |
| Sphere of application | Intermittent power on (5%) |
| Biometry | DC24V is powered on for 0.5 seconds and powered off for 10 seconds as a cycle (test life is more than 50,000 times) |
Dimension drawing of electromagnet
Solenoid electrical parameters
Product life: the service life of a product refers to the number of times of a cycle when the product is powered on and off, and a cycle is recorded as a life span. The product is used under normal conditions, and its service life is 500000 times.
Product temperature resistance: product temperature resistance refers to the temperature at which the product can work under high temperature. In general, the temperature resistance of conventional products does not exceed 120 ℃. For electromagnet industry, the temperature resistance can reach 220 ℃, which can be determined according to customer requirements.
Working environment and temperature: because of the temperature difference between the South and the north, and the environmental temperature in spring, summer, autumn and winter, the electrical parameters of the product will also change with the change of temperature. The main change is the resistance of the product. The resistance will increase with the heat of the weather and decrease with the cold weather. Therefore, these factors should be taken into account. The working temperature can work between - 30 ℃ and 220 ℃ .
Supply Ability
Supply Ability:1000000 Piece/Pieces per Month
Packaging & Delivery
PortGuangdong, shenzhen
Lead Time :
-
| Quantity(Pieces) | 1 - 500 | 501 - 1000 | 1001 - 5000 | >5000 |
| Est. Time(days) | 10 | 15 | 20 | To be negotiated |
-
-
